Produced strictly in accordance with international standards
Features premium pipe-grade glaze in white, sky blue, and cobalt blue
Applied using cold penetration and multi-layer thin glazing techniques
Equipped with welding neck flanges and automatic welding, ensuring weld seams are kept distant from the flange face
| Glass-Lined 45° Elbow Parameter Table | ||||||||||||||
 | DN（mm） | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 400 |
L（mm） | 107 | 114 | 118 | 128 | 135 | 143 | 162 | 169 | 191 | 235 | 274 | 318 | 397 | |
| Glass-Lined 90° Elbow Parameter Table | ||||||||||||
 | DN（mm） | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 |
L（mm） | 95 | 105 | 110 | 125 | 135 | 145 | 155 | 175 | 200 | 260 | 310 | |
